KST-F DN125 双球橡胶防震接头

KST-F DN125 双球橡胶防震接头

日期:2018-5-25

上海淞江减震器集团有限公司官方网站为您介绍:KST-F DN125 双球橡胶防震接头信息,淞江集团为众多空调、消防、液压、食品、等管道提*减震降噪解决方案,配套双球橡胶防震接头,让震动更低,让噪音更小。
Shanghai Songjiang shock absorber Group Co., Ltd. official website for you: KST-F DN125 double ball rubber shockproof joint information, Songjiang group for a number of air conditioning, fire, hydraulic, food, and other pipelines to provide shock absorption and noise reduction solutions, supporting double ball rubber shock joint, so that the vibration is lower, so that the noise is smaller.

TS压力管道生产许可证:TS编号TS2731B90-2020
TS pressure pipe production license: TS number TS2731B90-2020

KST-F DN125 双球橡胶防震接头

KST-F DN125 双球橡胶防震接头

KST-F DN125 双球橡胶防震接头

KST-F DN125 双球橡胶防震接头

KST-F DN125 双球橡胶防震接头

口径:DN125mm
英寸:5”
总长:215mm
轴向伸长:30mm
轴向压缩:50mm
横向位移:40mm
偏转角度:35°
工作压力:1.6Mpa
螺栓孔中心距:210mm
螺栓孔数:8个
螺栓孔径:18mm
橡胶材质:天然橡胶(也可以选择三元乙丙橡胶、丁腈橡胶)
法兰材质:碳钢法兰(也可以选择PVC法兰、不锈钢法兰)
品*:松夏
厂家:上海淞江减震器集团有限公司
Caliber: DN125mm
Inch: 5. “
Chief: 215mm
Axial elongation: 30mm
Axial compression: 50mm
Lateral displacement: 40mm
Deflection angle: 35 degrees
Work pressure: 1.6Mpa
Center distance of bolt hole: 210mm
Number of bolt holes: 8
Aperture of bolt: 18mm
Rubber material: natural rubber (also can choose three yuan ethylene propylene rubber, nitrile rubber).
Flange material: carbon steel flange (also can choose PVC flange, stainless steel flange).
Brand: Matsu
Factory: Shanghai Songjiang shock absorber Group Co., Ltd.

说明:松夏是淞江集团旗下的高端品*,我厂所有:双球、丝扣、异径、耐油、高温、酸碱、球体上面都刻有松夏字样,避免与普通过水产品混搅,更避免了不良商家拿我们普通过水产品充当*产品去给客户使用,导致客户使用后质量不*,危害客户,损坏淞江集团品*形象。
Explanation: the high-end brand of Song Xia is under the banner of Song Jiang Group, our factory all: double ball, silk buckle, different diameter, oil resistance, high temperature, acid base and ball, which are all engraved with summer words, avoid mixing with ordinary water products, and avoid the bad merchants taking our ordinary water products as a product to the customers, leading customers to use them. Poor quality after use, harming customers and damaging the brand image of Songjiang group.
